ME Static Mixers - Machine

STATOMIX ME series plastic disposable mixers, when used with meter mix equipment, provide a low cost solution for 2-component mixing. The mixer element is molded of polyacetal to withstand the higher pressures of meter mix machines. STATOMIX ME series mixers are also available with support washers. The washer will prevent the elements from extruding out the end of the housing when working with high pressure applications. STATOMIX ME mixers are suitable for all types of meter, mix and dispensing systems. Check with our sales department for the correct mixer for your equipment.

NOTE: The only functional difference between ME series and MS series is the inner diameter of the bell inlet housing: ME = .625 inches and MS = .657 inches



Technical Data
Outer Housing Polypropylene Elements Polyacetal
Retaining Nuts 7/8" - 9 thread or 7/8" - 14 thread I.D. Bell Inlet Housing 0.625 inches

Specifications (³æ¦ì: mm)
Part No. Inner Dia. I.D. (mm) Number of Elements Outer Dia. O.D. (mm) Length L (mm) Nozzle Dia. A (mm) Approx. Content Vol (ml)
ME 05-24 5 24 8 149 1.5 2.3
ME 05-32 5 32 8 188 1.5 2.8
ME 06-24 6.35 24 10 185 1.9 4.2
ME 06-32 6.35 32 10 234 1.9 6.6
ME 06-48 6.35 48 10.5 334 2.2 10
ME 08-24 8 24 12 223 2.4 8.5
ME 08-32 8 32 12 287 2.4 11.5
ME 10-24 10 24 14 276 3 16
ME 10-32 10 32 14 352 3 23
ME 1012-0832 10.00-8.00 12 + 32 14.00-12.00 409 2.4 19
ME 13-24 13 24 17 293 4 27
ME 13-24-L 13 24 17 350 4 27
ME 13-32 13 32 17 379 4 34.5
ME 13-32-L 13 32 17 451 4 34.5
ME 1312-1032 13.00-10.00 12 + 32 17.00-14.00 499 7.2 37.5
Retaining Nuts for ME Series Mixers
Part Number Description For I.D. (mm) Thread
UM 08-PA PA 6, Beige 5-8 7/8" - 9 Thread
UM 10-PA PA 6, Beige 5-10 7/8" - 9 Thread
UM 13-PA PA 6, Beige 13 7/8" - 9 Thread
UM 10-14-PA PA 6, Grey 5-10 7/8" - 14 thread
UM 13-14-PA PA 6, Grey 13 7/8" - 14 thread
