GB-1901 Dual Microcomputer Valve Controller (Low-pressure)

► GB-1901 Dual Microcomputer Valve Controller

(Low-pressure)

　▐　Specialty



Outstanding Dispensing Stability
Manual / Teaching / Automatic Mode
Intervals Settable for Loop Dispensing
40 Sets Program Capacity
Shot Time Range Achieve 0.01 sec



　▐　Function



Dispenser Tip Automatic Position
I/O Port Automatic Systems Allowed
Dispensing Procedure Portable by USB
1 Year Standard Warranty
PTP/CP 3D Dispensing Routes




　▐　Specification

　　Contact us to tell us your requirements, we will get back to you ASAP.


Function

GB-1901

Power Input

AC110 / 220V, 50 / 60 Hz

Input Voltage

24 VDC / 0.5 MA

Switch Voltage

24 VDC

Air Input

0~7 kg / cm²

Air Output

0~3 kg / cm² (Low-pressure)

Shot Time Range

Digital Timer 0.01~99.99 sec

Program Capacity

40 Programs / td

Vacuum

Adjustable

Weight

1.7 kg
